Pneumatic Auto Carton Sealer-TFXJ-5050Q
|
|
TFXJ-5050Q |
|
Product Description
The machine is mainly useful for the sealing and packing of cartons, which can be single-unit operation or also equipped into production line. It is used in the fields of electrical domestic appliance, foodstuffs, general merchandise, medicine and chemical industry.
|
Specifications |
FXJ-5050Q |
|
Voltage(V/Hz) |
AC 220/50 110/60 |
|
Power(W) |
220 |
|
Max. Carton Size(W×H)(mm) |
500 × 500 |
|
Min. Carton Size (W×H)(mm) |
170 × 100 |
|
Speed(Sec/Turn) |
24 |
|
Available Adhesive Tape |
BOPP Water-free Adhesive Tape PVC Adhesive Tape |
|
Height of Table(mm) |
600-780 |
|
Width of Adhesive Tape(mm) |
48 60 76 |
|
Air compressor |
2/3 升 |
|
Dimension (L×W×H)(mm) |
1970×660×(1280-1460) |
|
Net Weight(kg) |
150 |
|
|
Auto Flap Carton Sealer-TFXJ-5050Z
|
|
TFXJ-5050Z |
Product Description
The machine is mainly useful for the sealing and packing of cartons, which can be single-unit operation or also equipped into production line. It is widely used in the fields of electrical domestic appliance, foodstuffs, general merchandise, medicine and chemical industry.
The top , side and back flap of the carton can be folded automatically, with high speed & smooth.
|
Specifications |
TFXJ-5050Z |
|
Voltage(V/Hz) |
AC 220/50 110/60 |
|
Power(W) |
260 |
|
Max. Carton Size(W×H×L)(mm) |
500×500×600 |
|
Min. Carton Size (W×H×L)(mm) |
130×130×180 |
|
Speed(m/min) |
22 |
|
Width of Adhesive Tape(mm) |
48 60 76 |
|
Air Compressor |
2/3 Litres at 5 bars |
|
Dimension (L×W×H)(mm) |
2720×950×(1200-1800) |
|
Net Weight(kg) |
180 |
|
|
Carton Edge Sealer-TJFX-5060
|
|
TJFX-5060 |
Product Description
This machine is used for sealing the edge slots of top-bottom flapping. It can be equipped onto automatic packing production line.
|
Specifications |
TJFX-5060 |
|
Voltage(V/Hz) |
AC 220/50 |
|
Power(W) |
720 |
|
Air Compressor (Mpa) |
0.5～0.6 |
|
Min.Carton Size(W×H×L)(mm) |
300×240×180 |
|
Max.Carton Size (W×H×L)(mm) |
600×500×500 |
|
Speed(m/min) |
20 |
|
Available Adhesive Tape |
BOPP Water-free adhesive tape PVC adhesive tape |
|
Height of Table(mm) |
700-850 |
|
Width of Adhesive Tape(mm) |
48 60 76 |
|
Weight of Packing Object(kg) |
2.5-30 |
|
Dimension (L×W×H)(mm) |
2300×1300×1650 |
|
Net Weight(kg) |
400 |
|
|
Auto Flap Carton Bottom Sealer-TDZF-5050
|
|
TDZF-5050 |
Product Description
The end of automatic folding and closure, and supporting the use of automated production lines.
|
Specifications |
TDZF-5050 |
|
Voltage(V/Hz) |
AC 220/50 |
|
Power(W) |
180 |
|
Air Compressor (Mpa) |
0.5～0.6 |
|
Speed(m/min) |
22 |
|
Min.Carton Size(W×H×L)(mm) |
200×160×110 |
|
Max.Carton Size (W×H×L)(mm) |
600×500×500 |
|
Available adhesive tape |
BOPP Water-free adhesive tape PVC adhesive tape |
|
Width of Adhesive Tape(mm) |
48 60 76 |
|
Dimension (L×W×H)(mm) |
2000×860×1700 |
|
Net Weight(kg) |
320 |
|
|
Gummed Tape Dispenser-TFX-800
|
|
TFX-800 |
Product Description
The gum tape machine is used for sticking reinforced gummed tape. The extended tape length can be adjusted. The machine is easy in operation and conforms to environment requirements.
|
Specifications |
TFX-800 |
|
Width of Tape (mm) |
20-80 |
|
Max. Tape Roll diameter (mm) |
200 |
|
Dimension (L×W×H)(mm) |
480×330×320 |
|
Weight (kg) |
35 |
|
