Working range

Max digging depth

4300mm

Max digging radius

5480mm

Discharge height of pullshovel

3820mm

Discharge height of bucket

2680mm

Discharge distance of bucket

620mm

Outside measurement

Total width

2100mm

Total height （in transit ）

3400mm

Total length （in transit ）

6850mm

Technical parameters

Power of engine

59-71kw

Capacity of loading bucket

0.9 m³

Capacity of pullshovel bucket

0.3 m³

Max digging force

>59Kg

Working pressure of hydraulic circuit

21Mpa

Travel of speed

40 km/h

Hydraulic cycle time

8.3 s

Loading lift ability

>25 KN
