Model BT-400C-Ⅰ

Cellophane Paper (film) Box Type Tridimensional Packing Machine

OPERATION INSTRUCTION

CONTENTS

1.     General description

2.     Working principle and packing flow scheme

3.     Illustrative appearance

4.     Packing dimensions

5.     Main technical parameters

6.     Packing materials

7.     Characteristics and structural features

8.     Mount

9.     Notice

10. Operation rule

11. Adjustment regulation

12. Fault and remove

13. Electric diagram

14. List of main electric apparatus

15. Pneumatic Routine Theory Graph and main components details

16. packing list

1.     General description

This machine is a general equipment which is suited to 3-D Pack different specification’s hard paper box with cellophane paper and OPP film. This machine is a new type whole automatic 3D packing machine which is designed creatively by ourself based on advanced technique of domestic and foreign same kind of products. It’s main characteristic is able to pack compositely boxes with varions stack way. It’s mainbody is a mechanic interlocking mechanism, using an advanced PLC touch screen control, compact structure, beautiful appearance , easy to operate and process automation.

This machine is suited widely to pack of middle and small box goods, for example, drug, health protector, nutriment, food, cosmetics, stationery, VCD tape, playing cards and cigarette. It has many functions which includes moistureproof, raising the additional value, level and decoration quality of products, is a ideal box type 3D packing equipment.

2.     Working principle and packing flow scheme

 BT-400C-I Cellophane Paper(film)Box-type tri-dimensional

Packing Machine applies a conveying belt and a box’s additive advice to feed packing goods. A series of mechanisms, as drawing paper (film), cutting paper (film), folding, wrapping, heat sealing, trimming and output mechanism, are used for the packing of goods. The heat sealing is used to reach effect of sealing, moistureproof and decoration after the sides are folded.

Cellophane paper (film) and an unsealing thread with a printed picture or whole information laser mark are glued by adhesive tape, that has the functions of

easy unsealing and defend false.

The packing flow scheme is shown as Fig.1

4.Packing dimensions

Length (L)……………………………………………………100~300㎜

Width (W)…………………………………………………… 80~400㎜

Height (H)…………………………………………………… 10~80㎜

5.Main technical parameters (see table.1)

Table 1

Capacity             15-30 packet/min

Power supply         220V  50Hz

Motor power          0.75Kw

Total power of heater   3.7 Kw

Overall dimensions    (L)2050×(W)2400(860)×(H)1950

Weight              880㎏

Suitable area         pack bigger box or multiboxes

6.Packing materials

a)       Cellophane paper:  be able seal by heat, moistureproof, 300#~600#

b)      OPP thin film: thickness 22µm~28µm

c)       Unsealing thread: various colour adhesive tape with width 1.2~3mm

Specification: transparent thread, single gold, full gold, bright gold. Transparent red letter, red letter on white bottom, golden letter on white bottom,  laser defend false, laser hollow out and so on.

7.Characteristics and structural features

(1) Packing speed is adjustable: This machine applied frequency converter. The packing speed can be changed according to various requirement.

(2) Packing dimension is adjustable: When the dimensions and specification of packing goods are changed, mould’s replacement and adjustment are required.

(3) Heat sealing temperature is adjustable: The heating plate’s temperatures at every sealing mouth are all controlled by PLC. The heating temperatures can be set and kept automatically according to environment temperature outside.

(4) Additive advice: It is an intermittent additive advice. User can choice desk box or conveying belt additive by himself.

8.Lnstal lment

(1) After opening box, user should check carefully that the machine has or hasn’t been damaged firstly, pay attention on machine’s deformation, and prevent the machine fall on ground.

(2) This machine should be installed horizontally on cement ground in room. The

rubber plates with 10mm thickness and same shape are padded under foundation legs to prevent damaging base and position movement.

(3) Electric installation: Switching-on 220V (50Hz or 60Hz) single phase power supply, after that you must check the rotation direction of motor , because this machine can not reserve rotation. Correct rotation direction of the motor is that rotation direction of the hand wheel should be counter-clock wise rotation as viewed from the front.

9.Notice

(1) Read carefully this instruction before using this machine

(2) Operation and maintenance of this machine should be implemented by special person

(3) At every cam, swing bar of the machine should be filled HJ-20 type mechanical oil before start.

(4) Grounding at appointed position on label for safety

(5) Cleaning the surface and cover of machine by using soft cloth with water and cleaner at regular intervals to keep machine’s clean

(6) If no use the machine during long time, cleaning the cutter, please. (use dimethyl benzene or ethyl alcohol)

(7) If the working state of the machine isn’t normal, you must stop it at once and check

(8) Working environment: temperature    +5℃~+35℃

Relative humidity   65~85%

10.Operation rule

(1) Preparation

1.1  Before start you should check strictly following:

a. Opening the rear cover and observe the electric box, check that connecting wire and apparatus avel are not loose or drop out

b. Chick that each mechanical fasteners are/are not loose, drop out and position movement of components.

1.2 Manual test: Put on the hand wheel, rotating machine clockwise and observing that each transmission parts are correct and normal or not

1.3 Electrification test: Switching-on power supply, after that you must check the rotation direction of motor, because this machine can not reserve rotation, The correct rotation direction of motor is that the rotation direction of the hand wheel should be counter clock wise rotation as viewed from the machine’s front. (before normal working, the hand wheel should be taken off)

(2) Operation

2.1 Switch on power, the PLC screen is brighten. Light touch it at any place in the screen that go into operating interface.

2.2 According to the requirements in the operation instruction switch on every heater’s switch and set up their temperatures. The temperatures of long sealing, left side sealing, right side sealing, upper trimming and lower trimming are about 130℃,120℃, 120℃,105℃ and 105℃, respectively.

2.3 If you use conveying belt, you should maintain definite packing goods on it.

2.4 Adjust the touch screen’s frequency to between 8 and 15, and then single strike “run” button to start.

2.5 Single strike “STOP” button, switch-off power, clean the platform and every components (It the case of no switch-off power, touching every moving parts is forbidden),

11.Adjustment regulation

Any operator must obey this instruction. The standard procedure of adjusting

synchronization of this machine is:

(1) Adjusting film’s feeding part.(adjusting cutter is included)

(2) Adjusting the sealing mouth of long sealing

(3) Adjusting the working state of side folder and folding cutter.

Simple explanation as following:

1). Adjusting of film’s feeding part

1.1 Adjusting cutter frame’s height: Adjusting the cutter frame’s position from cutting plane to platform plane, this distance equals sum of half film’s length and half packing box’s height.

1.2 Adjusting film’s position: Adjusting only two moving press disks on the left and right film’s rolling shafts until suitable position.

1.3 Adjusting unsealing thread’s position: If you want to change the position of unsealing thread, you need only to rotate the stud on the unsealing thread frame.

1.4 Adjusting the small cutter: If the cutting position of the small cutter isn’t the position of unsealing thread, then loose the set screw of the small cutter is required, and then move the small cutter to the unsealing thread’s position. If the position of cut-off of small cutter isn’t appointed position, then loose the set screw on small cutter bed, up-down adjusting the cutter bed until the cut-off position of small cutter reaches appointed position.

2). Adjusting the sealing state of long sealing: Observe machine operation, if the long sealing can’t be completed, them.

(a) Adjusting the upper folding cutter’s position, making the upper film of box can be folded down smoothly.

(b) Adjusting the position and temperature of the scald seal plate of long sealing mouth, making the lower film of box can be folded up smoothly and can be sealed with upper film.

3).Adjusting the working state of side folder and folding cutter:

(a) When adjusting the folder, only to loose its installing screw, is required and more it left-right until the optimal position of side folding and screw down its set screw.

(b) When adjusting the folding cutter, only to loose the set screws of three cutter beds, is required more whole cutter bed left-right until the optimal position of folding, and then screw down.

12. Fault and remove (see table 2)

Table 2

13.List of main electric apparatus(电器图纸)

List of main electric apparatus

16．Packing list

table 4
