Technical Parameters£º

blade diameter: 5.0m
number of blades: 3
blade material: fiber glass
rated wind speed: 10m/s
start wind speed: 3m/s
working wind speed: 3-25m/s
security wind speed: 40m/s
rated output power: 3kw
max output power: 4.5kw
rated speed: 240r/min
type of generator: permanent-magnets- 3 phase A.C.
speed regulation: yaw& magnetic resistance
output voltage : DC192V
tower type: pull wire tubular tower
normal tower height: 8m
weight of top section: 215kg
Necessary battery: 12V 100AH 16 pieces
Net weight:442kg
Gross Weight:531kg
The wooden packing size :95X52X52
