Item |
Content |
Unit |
Parameters |
|
Whole car parameters
|
L×W×H |
mm |
8750×2500×3110 |
|
Feeding height |
mm |
1500 |
|
Gross weight |
kg |
12000 |
|
Pump send system
|
Type |
|
Level single action
hydraulic piston
|
|
Distributing valve type |
|
“S”valve
|
|
Transportation state |
|
Large displacement
/high
pressure |
|
Max grain diameter
|
mm |
40(125A) |
|
Concrete slumps area |
mm |
80-230 |
|
Hopper volume |
m³ |
0.8 |
|
Power system |
Diesel engine model
|
|
VOLVO TAD720VE |
|
Power
/rotate
speed |
kW/r/min |
174/2300 |
|
Main technical parameter |
Max theory deliver amount
|
High pressure |
m³/h |
65 |
|
Large displacement condition |
115 |
|
Pumping concrete rated
power |
High pressure |
MPa |
12 |
|
Large displacement condition
|
6 |
|
Master cylinder diameter
x journey |
mm |
φ140x1700 |
|
Transmission cylinder
diameter x journey |
mm |
φ230x1700 |
|
Pumping frequency |
High pressure |
次/分钟 |
15 |
|
Large displacement condition |
27 |
|
Hydraulic pumping system |
MPa |
32 |
|
Distribution system oil
pressure |
MPa |
19 |
|
Landing leg
、beat
up、oil
pressure washing system |
MPa |
12 |
|
Hydraulic tank capacity |
L |
550 |
|
Chassis parameters
|
Brand |
|
East wind |
|
Underpan type |
|
EQ1126KJ1 |
|
Engine model |
|
ISDe160-30 |
|
Engine power |
kW |
118 |
|
Wheel base |
mm |
4700 |
|
Emission standard
|
|
Country
Ⅲ |
|
Fuel tank capacity
|
L |
2X120 |
|
Max speed |
km/h |
90 |
