Item |
Content |
Unit |
Parameter |
|
Concrete
Pumping
System |
Type |
|
Level single action
biserial
Hydraulic piston
|
|
Distribution valve type
|
|
“S”valve
|
|
Feed status |
|
Large displacement
/
high pressure
|
|
Max theoretical delivery
valve |
m³/h |
88/49 |
|
Concrete pumping rated
power |
MPa |
8/16 |
|
Max bone grain diameter
|
mm |
40(125A) |
|
Concrete slump range
|
mm |
80-230 |
|
Master cylinder diameter
x journey |
mm |
φ140x1800 |
|
Transmission cylinder
diameter x journey
|
mm |
φ200x1800 |
|
Bucket capacity/feeding
height |
m³/mm |
0.8/1470 |
|
Power
System |
Diesel engine model
|
|
VOLVO TAD720VE |
|
Power
/rotate
speed |
kW/r/min |
174/2300 |
|
Liquid
System |
Hydraulic pumping system
|
MPa |
32 |
|
Distribution system oil
pressure |
MPa |
19 |
|
Mixing system oil
pressure |
MPa |
12 |
|
Hydraulic oil tank
capacity |
L |
500 |
|
Other |
Diesel tank capacity
|
L |
220 |
|
Gross mass |
kg |
7200 |
|
Outside dimension
L X W X H |
mm |
6930x2110x2640 |
|
Drag-line speed
|
km/h |
≤8 |
