Technical ( designed) Parameter			Major dispositions and Technical pecification
Name	Inside equipment	Inside jacket	1Surficial treatment; the inside and outside surface of equipment is treated by mirror surface , make sure that  there is no  hygienic dead angle.   2 Material and Thickness; liner of tank¦Ä=3mm/SUS304;jacket¦Ä=3mm/SUS304; insulating course¦Ä=2mm/SUS304   3 Stirring system; Adopt explosion-proof electric machine, mechanical seal, double¨Carm agitating valve. 4 The layout of tank : handhole, sight glass, Cleaning Ball, fire arrestor. . ¡¡ 5 Wet part is made of stainless steel£¨SUS304£©
Working  pressure    Mpa	normal atmosphere	normal atmosphere
Designed  pressure   Mpa	normal atmosphere	normal atmosphere
Working   tempreture  ¡æ	100	100
Name  of  material    ¡æ	Liquid of traditional Chinese medicine	saturated steam
Material of major press element	SUS304 3mm	Q235B 3mm
Designed  tempreture	105	105
Working  volume           m3	0.5
Total  volume              m3	0.51
Stirring motor
Area of heat exchange	1.8

¡¡
