Cereal color sorter
RA Cereal Color Sorter
|
Name |
RA4 Cereal |
RA6 Cereal |
RA8 Cereal |
|
Type |
6SXM-160A-CK |
6SXM-240A-CK |
6SXM-320A-CK |
|
Channels |
160 |
240 |
320 |
|
Throughput£¨t/h£© |
<3.0 |
<4.5 |
<9.0 |
|
Sorting accuracy(%) |
>99.5 |
>99.5 |
>99.5 |
|
Optimized carryover (bad
:good) |
>4:1 |
>4:1 |
>4:1 |
|
Channels preset for primary
sorting and re-sorting |
120:40 |
160:80 |
240:80 |
|
Voltage (V) |
~220(50Hz) |
~220(50Hz) |
~220(50Hz) |
|
Power of main machine (kW) |
1.5 |
2.2 |
3.0 |
|
Air Pressure (MPa) |
0.6~0.8 |
0.6~0.8 |
0.6~0.8 |
|
Air consumption (m3/min) |
<1.8 |
<2.5 |
<3.0 |
|
Weight (kg) |
750 |
850 |
900 |
|
Dimension (L¡ÁW¡ÁH)£¨mm£© |
1423¡Á1410¡Á2040 |
1920¡Á1410¡Á2040 |
2043¡Á1410¡Á2040 |
RB Cereal Color Sorter
|
Name |
RB6 Cereal |
RB8 Cereal |
|
Type |
6SXM-240B-CK |
6SXM-320B-CK |
|
Channels |
240 |
320 |
|
Throughput£¨t/h£© |
<4.5 |
<6.0 |
|
Sorting accuracy(%) |
>99.5 |
>99.5 |
|
Optimized carryover (bad
:good) |
>4:1 |
>4:1 |
|
Channels preset for primary
sorting and re-sorting |
160:80 |
240:80 |
|
Voltage (V) |
~220(50Hz) |
~220(50Hz) |
|
Power of main machine (kW) |
2.2 |
3.0 |
|
Air Pressure (MPa) |
0.6~0.8 |
0.6~0.8 |
|
Air consumption (m3/min) |
<2.5 |
<3.0 |
|
Weight (kg) |
850 |
900 |
|
Dimension (L¡ÁW¡ÁH)£¨mm£© |
1920¡Á1410¡Á2040 |
2043¡Á1410¡Á2040 |
CB6 Cereal Color Sorter
¡¡
|
Name |
CB6 |
|
Type |
6SXZ-240B-CK |
|
Channels |
240 |
|
Throughput£¨t/h£© |
<4.0 |
|
Sorting accuracy£¨%£© |
>99 |
|
Contaminant Reject Ratio£¨%£© |
>92 |
|
Optimized carryover (bad
:good) |
>8:1 |
|
Channels preset for primary
sorting and re-sorting |
160:80 |
|
Voltage (V) |
~220(50Hz) |
|
Power of main machine (kW) |
2.9 |
|
Air Pressure (MPa) |
>0.4 |
|
Air consumption (m3/min) |
<3.0 |
|
Weight (Kg) |
800 |
|
Dimension (L¡ÁW¡ÁH)£¨mm£© |
2025¡Á1395¡Á1875 |
Note:
All the performance data listed
above is taken the 5%-contaminant
yellow bean with output capacity 3
t/h as example, and the actual index
is to be altered subject to the
material and content of the
contaminants
